Red Jacket Electric Submersible Pump With Motor

FOB Reference Price:Get Latest Price
$730.00 - $740.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
TDW
Model Number:
TDW-ESP150
Structure:
Multistage Pump
Usage:
Oil/Water
Application:
Submersible
Power:
Electric, 1.3KW
Fuel:
Diesel/Gasoline
Pressure:
Low Pressure
Rated Current:
9.5A
Rated Voltage:
AC220V
Outlet Pressure:
≤0.25MPa
Nominal Flow Rate:
250L/m
Protection Lever:
IP54
Efficiency:
≥0.69
Rated Speed:
2850r/min
Frequency:
50HZ
Noise:
≤68dB
Standard or Nonstandard:
Standard
Theory:
Centrifugal Pump
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
Each fuel transfer pump with plastic bubble bag, then in a carton, with tray.
Port
ShangHai or NingBo
Lead Time :
15 days

Red Jacket Electric Submersible Pump With Motor

Product Description

Application and applicable environment
Submersible pump is an oil conveying equipment which is widely applied to
Transferring oils including:



Gas
0 15 mixture of alcohol or methanol and gasoline.
Diesel
ρ≤0.95 10 × 3Kg/m3.
figure1
ESP -250 Submersible Pump Operating Instruction
line and gasoline mixture:
Mixture of 20%MTBE and 80% gasoline.
Mixture 20% ETBE and 80% gasoline.
Mixture 17% TAME and 83% gasoline.


Aviation Kerosene
1.2The mix, viscosity of transferring oils is 13x10 m /s (or 70SSU) at 15 .and -6 2 ℃
1.3 Ambient temperature:-20 40 ℃~+ . ℃
1.4 Except the above-mentioned oils, it is lack of reliable data to judge the applicability
of other oils. So it could be potential danger to transfer other oils with submersible pump.



such as fuel discharge.
Pull-out design of the assemblies makes maintenance easy and convenient.
Vertical design of the oil outlet completely corresponds with the trend of outlet hose
connecting and leak detector installing.





Packaging & Shipping

You may like our other flow meter, fuel transfer pump for fuel dispenser.(Click!)

Company Information



FAQ & Contact

1- Could you develop our own design?                             Yes
2- The fuel nozzle including swivel?                                 Yes
3- Can we visit your factory?                                           Yes
4- Could you send the sample for testing?                       Yes
5- Could you offer door to door service?                           Yes
